High Rigidity & High Torque Speed Reducer

AHB series High precision Standard Backlash Speed Reducer

This helical gear reducer features ultra-quiet operation, superior precision, excellent structural rigidity and strong torque output. Built with adapter-bushing connection, it boasts wide compatibility with different types of motors. Utilizing dedicated high-viscosity anti-separation grease, it achieves long-term maintenance-free performance and allows installation in any position. Reliable and versatile, it serves as a perfect solution for various precision motion control systems.

Item No :
AHB series
Order(MOQ) :
20
Payment :
Paypal/TT/Western Union
Product Origin :
Jiangsu, China
Lead Time :
18-30 days
Weight :
2kg

Inquiry Now

Beitto helical gear reducer operates quietly with minimized vibration thanks to helical gear design. It delivers high transmission precision with a standard backlash of 3 arc-min, perfectly suited for precision control scenarios. Fitted with uncaged needle roller bearings, the unit features exceptional rigidity and high torque capacity. The adapter-bushing connection ensures great compatibility with various motors. Adopting special high-viscosity anti-separation grease, the reducer requires no grease replacement during its entire service life for maintenance-free operation, and it can be installed in any position to fit diverse application layouts.

Product Features

Quiet operation. Helical gears contribute to reduce vibration and noise.
High precision. Standard backlash is 3 arc-min, ideal for precision control.
High rigidity &high torque were achieved by uncaged needle roller bearings.
Adapter-bushing connection. Motor generality
High viscosity grease. Perfect solution using high viscosity anti-separation grease.
Maintenance-free. No need to replace the grease for the life of the unit. Can be attached in any position.

Technical Specifications

Example: AHB-042

Frame size	Model	Ratio	Nominal output torque [Nm]	Maximum output torque [Nm]	Emergency stop torque [Nm]	Nominal input speed [rpm]	Maximum input speed [rpm]	Permitted radial load [N]	Permitted axial load [N]
042	Single Stage	3	7	14	35	4000	8000	250	280
042	Single Stage	4	10	20	40	4000	8000	280	310
042	Single Stage	5	10	20	40	4000	8000	300	340
042	Single Stage	6	10	20	40	4000	8000	320	370
042	Single Stage	7	10	20	40	4000	8000	330	390
042	Single Stage	8	10	20	40	4000	8000	350	420
042	Single Stage	9	7	14	35	4000	8000	360	440
042	Single Stage	10	7	14	35	4000	8000	370	460
042	Double Stage	15	7	14	35	4000	8000	420	550
042	Double Stage	16	10	20	40	4000	8000	430	560
042	Double Stage	20	10	20	40	4000	8000	470	620
042	Double Stage	25	10	20	40	4000	8000	500	650
042	Double Stage	28	10	20	40	4000	8000	520	650
042	Double Stage	30	7	14	35	4000	8000	530	650
042	Double Stage	35	10	20	40	4000	8000	560	650
042	Double Stage	40	10	20	40	4000	8000	580	650
042	Double Stage	45	7	14	35	4000	8000	610	650
042	Double Stage	50	10	20	40	4000	8000	630	650
042	Double Stage	60	10	20	40	4000	8000	670	650
042	Double Stage	70	10	20	40	4000	8000	700	650
042	Double Stage	80	10	20	40	4000	8000	720	650
042	Double Stage	90	7	14	35	4000	8000
